Description
The M288 Bass Octave Deluxe is a two-voice octave pedal. It’s an analog pedal with quite flexible and diverse settings. The Dry potentiometer adjusts the blend of the clean signal, while using the MID+ adds +14dB. The Growl and Girth controls allow you to adjust the type of octave.
Features:
- Effect Type: Bass Octaver
- Adjustment Options: Mid+ Switch / Growl / Dry / Girth
- Power Supply: 9V
- Input Impedance: 1 MΩ
- Output Impedance: < 600 Ω
- Noise Floor: 85 dB
- Octave Bandpass: -3 dB, 8 Hz to 46 Hz
- Control Range: Dry: -? to +2.5 dB, Girth: -? to +1 dB, Growl: -? to +6 dB
- MID+ Switch: Gain +4 dB to +14 dB, Frequency 400 Hz or 850 Hz
- Bypass: True Hardwire
- Current Draw: 14 mA
